Elastec MediBurn30 - Chamber Brick Assembly Parts List

MEDIBURN30 31 D-115 Rev 010
www.elastec.com
CHAMBER BRICK ASSEMBLY PARTS LIST
0KIT-BR030 MediBurn 30 Brick Kit
Item# Part # Description Qty.
1 4BRICME042 Brick/MB End Chamber Top Front 1
2 4BRICME028 Brick/MB Chamber 29
3 4BRICME004R1 Brick/MB Baffle 3” (2 Piece Set) 3
4 4BRICME018 Brick/MB Chamber Left 10” Hole 2
5 4BRICME024 Brick/MB Chamber Right 10” Hole 2
6 4BRICME014 Brick/ MB Chamber End Top Back 1
7 4BRICME034 Brick/MB Door Lip Plate 1
8 4BRICME022 Brick/MB Chamber Rectangle Hole 1
9 4BRICME019 Brick/ MB Chamber Left 8” Hole 1
10 4BRICME025 Brick/MB Chamber Right 8” Hole 1
11 4BRICME012 Brick/MB Chamber End Bottom 1
12* 4BRICME039 Brick/MB Door Square (2 Piece Set) 1
13* 4BRICME044 Brick/MB Stack 10” Hole 1
14* 4BRICME008 Brick/MB Between Chambers 8” Hole 1
15* 4TAPEDO010 Tape Double Adhesive 1/16” x 3/4” 4016 2
16* 4INSUCE012C Insulation Ceramic 1/8” x 24” x 44-1/2” 12
17* 4INSUCE016C Insulation Ceramic 1” 1
18* 4ANCHRE032C Anchor Refractory 2” 12
19* 4BIT-DR030 Bit Drill 1” x 6” MB30 1
20* 0KIT-HA040 Kit Hardware MB Bolts 1
21* 0KIT-HA030 Kit Hardware MB20/30 UnderAir 1
22* 0KIT-HA020 Kit Hardware MB Door Bolt 1
* — Item not shown
