Elastec MediBurn30 - Parts Lists (Under-Air & Spare)

MEDIBURN30 33 D-115 Rev 010
www.elastec.com
0KIT-SP133 Spare Parts Kit List
Part # Description Qty.
4BURNHE220 Burner Head F220 1
0KIT-HA020 Kit Hardware MB Door Bolt 1
0KIT-HA030 Kit Hardware MB30 UnderAir 1
0KIT-HA040 Kit Hardware MB Bolts 1
4DETECA010 Detector Cad Cell 2
4NOZZBU250 Nozzle Burner 2.50 2
4THERCO000C Thermocouple MB Complete 8
4FILTFU510 Filter Fuel Water Blck 4
4SILIHI030 Silicone High Temp Red RTV 3 oz Tube 1
4BURNHE160 Burner Head F160 1
4NOZZBU200 Nozzle Burner 2.0, 60 Degree 2
4CLAMTO202C Clamp Toggle Complete 2
4FUSEME030 Fuse MediBurn Slow Blow 1.25 Amp 5x20mm 10
4FUSEME031 Fuse MediBurn Slow Blow 2.5 Amp 5x20mm 10
4FUSEME032 Fuse MediBurn Slow Blow 10 Amp 5x20mm 10
4FUSEME033 Fuse MediBurn Slow Blow 15 Amp 5x20mm 10
4FUSEBL004 Fuse Blade-style Low-voltage Standard 4 Amp 2
4REFRBU020 Refractory Repair Material 10 lbs
4BRICME034 Brick/MB Door Lip Plate 1
4GASKCE010 Gasket Ceramic 1/8” x 2” 23
PARTS LISTS
Under-Air Parts List
Item# Part # Description
16 4MOTODA010 Motor Damper, 24 Volt
17 4VALVBU010C Valve Butterfly 2”
18 4PLENUN010P Plenum Under Air
19 4PIPEEX030P Pipe, Exhaust, Tee, MB 30
20 4PIPEEX033P Pipe, Exhaust, Coupler, MB 30
21 4PIPEEX034C Pipe, Exhaust, Inlet Tube, MB 30
22 4PIPEEX031P Pipe Exhaust Tee
