MEDIBURN30 15 D-115 Rev 010
www.elastec.com
1. Position unit on a level surface at least 2 meters (7 feet) away from existing
structures. Please ensure that there are no overhangs from the building or
overhead wires above the exhaust stack.
2. Connect the electrical plug extending from the control panel of the unit to an
appropriate extension cord. Cord should be no lighter than 12 gauge at 7.5
meters/25 feet. If a longer cord is needed, a heavier gauge wire is required.
3. If you chose the gravity-fed option (see “Hook-Up,” Page 6), connect the fuel
supply to the burners on the unit with the quick-connect couplings provided.
NOTE: You may be required to bleed air from the fuel system before the first
burn. Refer to the burner parts list for instructions. See below for
connecting a gravity fuel supply system. The fuel tank should be mounted
so that the bottom of the fuel tank is higher than the secondary burner.
NOTE: If the unit has an on-board fuel tank, the gravity fuel supply system
will not be needed.
4. Check door gasket before each use.
Quick-Connect for Optional
Gravity Fuel System
Minimum
Height
Gravity Fuel Supply
System
Fuel Filter
Mounted Tank
(If Applicable)
Secondary
Burner
PREPARING FOR DISPOSAL
