elco TRIGON XXL Series Planner Documentation

Technical description
Technical data
TRIGON XXL-EVO
TRIGON XXL EVO
1200 1400 1550 1700 2000
Nominal heat output at 80/60ºC max/min kW 1141/324 1304/371 1467/417 1562/464
1953/487
Nominal heat output at 40/30ºC max/min kW 1218/365 1393/418 1566/469 1741/522 2087/548
Nominal heat input Hi max/min kW 1166/333 1333/381 1449/428 1666/476 2000/500
Efficiency at 80/60ºC % 97,8
97,6
Efficiency at 40/30ºC % 109,7
RAL 40/30 average % 108,4
Max. condensate flow l/h
75,6 86,5 97,2 108,1 75,5
Gas consumption G20 max/min (10,9 kWh/m
3
) m
3
/h 107/30,6 122,3/35,0 137,5/39,3 152,8/43,7
183,5/52,4
Gas consumption G25 max/min (8,34 kWh/m
3
) m
3
/h 139,8/39,9 159,8/45,7 179,7/51,3 199,8/57,1 293,8/68,5
Gas consumption G31 max/min (12,8 kWh/kg) kg/h 91,1/26,0 104,1/29,8 117/33,4 130,2/37,2 156,3/44,6
Gas pressure H-gas mbar 35
50
Gas pressure L-gas mbar 35
50
Gas pressure LPG mbar 50
Maximum gas pressure mbar 100
Flue gas temperature at 80/60ºC max/min ºC 69/59
73/59
Flue gas temperature at 40/30ºC max/min ºC 51/32
Flue gas quantity max/min m
3
/h 1795/529 2052/605 2307/680 2565/756
CO2 level G20-G25 max/min % 10.0/10.2
CO2 level G31 max/min % 11.0/11.2
NOx level at 80/60 °C max/min mg/kWh 37/22
32/23
CO level at 80/60 °C max/min mg/kWh 4/2
Max. permissible flue resistance Pa 150
Water volume l 131 147,2 156,6 166,1 209,0
Water pressure max/min bar 8/1.5
Max. water temperature (High limit thermostat)
ºC 100
Maximum temperature setpoint ºC 90
Nominal water flow at dT=20K m
3
/h 49,0 56,1 63,1 70,1 84,0
Hydraulic resistance at nominal flow rate kPa 82 96 136 162
216
Electrical connection V 400
Frequency Hz 50
Mains connection fuse A 16
IP class - IP00
Electrical consumption boiler max/min (without pump) W 2330/585 2770/695
Weight (empty) kg 1900 2000 2100 2201 2500
Sound Power Level (LWA) dB 68,7
72,7
Ionisation current max µA 0.52
PH value condensate - 3,2
CE certification code - CE 0063CR3158
Water connections - DN80PN16
Gas connection - DN65 PN16 DN80PN16
Flue gas connection (DN) mm 450
500
Air intake connect. (room sealed use) (DN) mm 450
Condensate connection mm 40
