Accessories
Controls
OUTDOOR SENSOR QAC34.101
The kit contains an outdoor sensor
QAC34.
HEADER/HOT WATER SENSOR
QAZ36 CABLE 6M
The kit contains a header/hot water
sensor QAZ36 with 6m cable and a
1/2" pocket.
Heating zone sensor QAD36
The kit contains a clamp sensor
QAD36 with 4m cable.
Extension module AVS75.390/101
TR-XXL
The kit contains an AVS75 extension
module incl. communication cable to
the LMS14 boiler management unit.
Maximum 3 AVS75 modules can be
connected to one boiler (module 1
and 2 for heating zone control, modu-
le 3 for other functions).
Commercial Gateway
The kit contains an interface to
connect the boiler to a BMS.
There are 4 kits:
- 1 boiler via KNX BACnet Modbus;
- max 4 boilers via KNX BACnet
Modbus;
- 1 boiler via LON;
- max 4 boilers via LON.
OZW672 WEB server
(to convert the boiler bus system to TCP/IP protocol)
Switch
(to make the connection on TCP/IP)
Gateway ProtoNode
(to make the communication with the BMS)
41
