8
TRIGON XXL ECO
650 750 850 950 1050
Nominal heat output at 80/60ºC max/min kW 615/175 719/204 814/231 909/258 1003/285
Nominal heat output at 40/30ºC max/min kW 625/195 732/227 828/257 925/287 1021/318
Nominal heat input Hi max/min kW 653/187 764/218 865/247 966/276 1066/305
Efficiency at 80/60ºC
% 94,1
Efficiency at 40/30ºC
% 104,1
RAL 40/30 average % 103,7
Max. condensate flow l/h 7,8 9,1 10,3 11,5 12,7
Gas consumption G20 max/min (10,9 kWh/m
3
) m
3
/h 59,9/17,2 70,1/20 79,4/22,7 88,6/25,3 97,8/28
Gas consumption G25 max/min (8,34 kWh/m
3
) m
3
/h 78,3/22,4 91,6/26,1 103,7/29,6 115,8/33,1 127,8/36,5
Gas consumption G31 max/min (12,8 kWh/kg) kg/h 51,0/14,6 59,7/17 67,6/19,3 75,5/21,6 83,3/23,8
Gas pressure H-gas mbar 20
Gas pressure L-gas mbar 25
Gas pressure LPG mbar 30
Maximum gas pressure mbar 100
Flue gas temperature at 80/60ºC max/min ºC 153/65
Flue gas temperature at 40/30ºC max/min ºC 134/64
Flue gas quantity max/min m
3
/h 1252/303 1465/353 1659/400 1852/447 2044/493
CO2 level G20-G25 max/min % 10,0/10,2
CO2 level G31 max/min % 11,0/11,2
NOx level at 80/60 °C max/min mg/kWh 37/22
CO level at 80/60 °C max/min mg/kWh 4/3
Max. permissible flue resistance Pa 150
Water volume l 53 70 75 80 85
Water pressure max/min bar 8/1,5
Max. water temperature (High limit thermostat)
ºC 100
Maximum temperature setpoint ºC 90
Nominal water flow at dT=20K m
3
/h 26 31 35 39 43
Hydraulic resistance at nominal flow rate kPa 37 25 30 35 40
Electrical connection V 400
Frequency Hz 50
Mains connection fuse A 16
IP class - IP00
Electrical consumption boiler max/min (without pump) W
900/225
1270/320
Weight (empty) kg 844 958 1084 1221 1369
Sound Power Level (LWA) dB 68,7
Ionisation current max/min µA 0,52
PH value condensate - 3,2
CE certification code - CE 0063CR3158
Water connections - DN65 PN16 DN80 PN16
Gas connection - DN50 DN65 PN16
Flue gas connection (DN)
mm 350 400
Air intake connect, (room sealed use) (DN) mm 355
Condensate connection mm 40
Technical description
Technical data
