elco TRIGON XXL Series Planner Documentation

Technical description
Technical data
6
TRIGON XXLSE
650 750 850 1000 1100
Nominal heat output at 80/60ºC max/min kW 650/164 726/183 849/213 961/242 1073/270
Nominal heat output at 40/30ºC max/min kW 657/183 733/204 858/238 971/270 1084/301
Nominal heat input Hi max/min kW 702/176 784/196 917/229 1038/260 1159/290
Efficiency at 80/60ºC
% 93.2
Efficiency at 40/30ºC
% 103,9
RAL 40/30 average % 103,3
Max. condensate flow l/h 3,2 3,6 4,2 4,8 5,3
Gas consumption G20 max/min (10,9 kWh/m
3
) m
3
/h 64,4/16,1 71,9/18,0 84,1/21,0 95,2/23,9 106,3/26,6
Gas consumption G25 max/min (8,34 kWh/m
3
) m
3
/h 84,2/21,1 94,0/23,5 110;0/27,5 124,5/31,2 139,0/34,8
Gas consumption G31 max/min (12,8 kWh/kg) kg/h 54,8713,8 61,3/15,3 71,6/17,9 81,1/20,3 90,5/22,7
Gas pressure H-gas mbar 20 35
Gas pressure L-gas mbar 25 35
Gas pressure LPG mbar 30 50
Maximum gas pressure mbar 100
Flue gas temperature at 80/60ºC max/min ºC 182/66
Flue gas temperature at 40/30ºC max/min ºC 167/65
Flue gas quantity max/min m
3
/h 1438/286 1606/318 1878/372 2126/422 2374/471
CO2 level G20-G25 max/min % 10,0/10,2
CO2 level G31 max/min % 11,0/11,2
NOx level at 80/60 °C max/min mg/kWh 45/23
CO level at 80/60 °C max/min mg/kWh 7/3
Max. permissible flue resistance Pa 150
Water volume l 50 53 70 75 80
Water pressure max/min bar 8/1,5
Max. water temperature (High limit thermostat)
ºC 100
Maximum temperature setpoint ºC 90
Nominal water flow at dT=20K m
3
/h 28 31 36 41 46,0
Hydraulic resistance at nominal flow rate kPa 46 53 36 43 50
Electrical connection V 400
Frequency Hz 50
Mains connection fuse A 16
IP class - IP00
Electrical consumption boiler max/min (without pump) W 900/225 1270/320
Weight (empty) kg 770 844 958 1084 1221
Sound Power Level (LWA) dB 72,7
Ionisation current min µA 0,52
PH value condensate - 3,2
CE certification code - CE 0063CR3158
Water connections - DN65 PN16 DN80 PN16
Gas connection - DN50 DN65 PN16
Flue gas connection (DN) mm 300 350 400
Air intake connect. (room sealed use) (DN) mm 250 355
Condensate connection mm 40
