elco TRIGON XXL Series Planner Documentation

Technical description
Technical data
TRIGON XXL-EVO
TRIGON XXL EVO
700 800 900 1000 1100
Nominal heat output at 80/60ºC max/min kW 639/182 747/212 846/241 945/269 1043/297
Nominal heat output at 40/30ºC max/min kW 682/205 798/239 904/271 1009/303 1114/334
Nominal heat input Hi max/min kW 653/187 764/218 865/247 966/276 1066/305
Efficiency at 80/60ºC
% 97,8
Efficiency at 40/30ºC
% 109,4
RAL 40/30 average % 108,4
Max. condensate flow l/h 42,4 49,6 56,1 62,7 69,1
Gas consumption G20 max/min (10,9 kWh/m
3
) m
3
/h 59,9/17,2 70,1/20,0 79,4/22,7 88,6/25,3 97,8/28
Gas consumption G25 max/min (8,34 kWh/m
3
) m
3
/h 78,3/22,4 91,6/26,1 103,7/29,6 115,8/33,1 127,8/36,6
Gas consumption G31 max/min (12,8 kWh/kg) kg/h 51,0/14,6 59,7/17,0 67,6/19,3 75,5/21,6 83,3/23,8
Gas pressure H-gas mbar 20
Gas pressure L-gas mbar 25
Gas pressure LPG mbar 30
Maximum gas pressure mbar
100
Flue gas temperature at 80/60ºC max/min ºC 69/59
Flue gas temperature at 40/30ºC max/min ºC 51/32
Flue gas quantity max/min m
3
/h 1005/297 1176/346 1332/393 1487/439 1641/485
CO2 level G20-G25 max/min % 10,0/10,2
CO2 level G31 max/min % 11,0/11,2
NOx level at 80/60 °C max/min mg/kWh 37/22
CO level at 80/60 °C max/min mg/kWh 4/2
Max. permissible flue resistance Pa 150
Water volume l 73 97 104 110 117
Water pressure max/min bar 8/1.5
Max. water temperature (High limit thermostat)
ºC 100
Maximum temperature setpoint ºC 90
Nominal water flow at dT=20K m
3
/h 27 32 36 41 45
Hydraulic resistance at nominal flow rate kPa 74 40 45 67 78
Electrical connection V 400
Frequency Hz 50
Mains connection fuse A 16
IP class - IP00B
Electrical consumption boiler max/min (without pump) W
900/225
1270/320
Weight (empty) kg 1136 1328 1468 1634 1800
Sound Power Level (LWA) dB 68,7
Ionisation current max/min µA 0,52
PH value condensate - 3,2
CE certification code - 0063CR3158
Water connections - DN65 PN16 DN80 PN16
Gas connection - DN50 DN65 PN16
Flue gas connection (DN) mm 300 350 400
Air intake connect. (room sealed use) (DN) mm 250 355
Condensate connection mm 40
