TRIGON XXL ECO
1150 1300 1450 1600
Nominal heat output at 80/60ºC max/min kW 1097/311 1255/356 1411/400 1568/445
Nominal heat output at 40/30ºC max/min kW 1117/347 1277/397 1436/446 1596/496
Nominal heat input Hi max/min kW 1166/333 1333/381 1449/428 1666/476
Efficiency at 80/60ºC % 94,1
Efficiency at 40/30ºC % 104,1
RAL 40/30 average % 103,7
Max. condensate flow l/h 13,9 15,9 17,9 19,9
Gas consumption G20 max/min (10,9 kWh/m
3
) m
3
/h 107/30,6 122,3/35 137,5/39,3 152,8/43,7
Gas consumption G25 max/min (8,34 kWh/m
3
) m
3
/h 139,8/39,9 159,8/45,7 179,7/51,3 199,8/57,1
Gas consumption G31 max/min (12,8 kWh/kg) kg/h 91,1/26 104,1/29,8 117,1/33,4 130,2/37,2
Gas pressure H-gas mbar 35
Gas pressure L-gas mbar 35
Gas pressure LPG mbar 50
Maximum gas pressure mbar 100
Flue gas temperature at 80/60ºC max/min ºC 153/65
Flue gas temperature at 40/30ºC max/min ºC 134/64
Flue gas quantity max/min m
3
/h 2236/576 2556/616 2874/692 3194/770
CO2 level G20-G25 max/min % 10,0/10,2
CO2 level G31 max/min % 11,0/11,2
NOx level at 80/60 °C max/min mg/kWh 37/22
CO level at 80/60 °C max/min mg/kWh 4/3
Max. permissible flue resistance Pa 150
Water volume l 97 109 116 123
Water pressure max/min bar 8/1,5
Max. water temperature (High limit thermostat)
ºC 100
Maximum temperature setpoint ºC 90
Nominal water flow at dT=20K m
3
/h 47 54 60,7 67,4
Hydraulic resistance at nominal flow rate kPa 60 72 93 114
Electrical connection V 400
Frequency Hz 50
Mains connection fuse A 16
IP class - IP00
Electrical consumption boiler max/min (without pump) W 2330/585 2770/695
Weight (empty) kg 1380 1740 1899 1991
Sound Power Level (LWA) dB 68,7
Ionisation current min µA 0,52
PH value condensate - 3,2
CE certification code - CE 0063CR3158
Water connections - DN80PN16
Gas connection - DN65PN16 DN80PN16
Flue gas connection (DN) mm
500 450
Air intake connect. (room sealed use) (DN) mm 450
Condensate connection mm 40
Technical description
Technical data
TRIGON XXL-ECO
9
