TRIGON XXL SE
1200 1300 1500 1700 1900
Nominal heat output at 80/60ºC max/min kW 1184/298 1296/326 1481/373 1666/419 1851/466
Nominal heat output at 40/30ºC max/min kW 1196/332 1309/363 1496/415 1684/467 1871/519
Nominal heat input Hi max/min kW 1279/320 1400/350 1600/400 1800/450 2000/500
Efficiency at 80/60ºC
% 93,2
Efficiency at 40/30ºC
% 103,9
RAL 40/30 average % 103,3
Max. condensate flow l/h 5,9 6,4 7,4 8,3 9,2
Gas consumption G20 max/min (10,9 kWh/m
3
) m
3
/h 117,3/29,4 128,4/32,1 146,7/36,7 165,1/41,3 183,5/45,9
Gas consumption G25 max/min (8,34 kWh/m
3
) m
3
/h 153,4/38,4 167,9/42,0 191,8/48,0 215,8/54,0 239,8/60,0
Gas consumption G31 max/min (12,8 kWh/kg) kg/h 99,9/25,0 109,4/27,3 125/31,3 140,6/35,2 156,3/39,1
Gas pressure H-gas mbar 35 50
Gas pressure L-gas mbar 35 50
Gas pressure LPG mbar 50
Maximum gas pressure mbar 100
Flue gas temperature at 80/60ºC max/min ºC 182/66
Flue gas temperature at 40/30ºC max/min ºC 167/65
Flue gas quantity max/min m
3
/h 2619/519 2867/568 3277/649 3685/730 4095/811
CO2 level G20-G25 max/min % 10,0/10,2
CO2 level G31 max/min % 11,0/11,2
NOx level at 80/60 °C max/min mg/kWh 45/23
CO level at 80/60 °C max/min mg/kWh 7/3
Max. permissible flue resistance Pa 150
Water volume l 85 97 109 116 123
Water pressure max/min bar 8/1,5
Max. water temperature (High limit thermostat)
ºC 100
Maximum temperature setpoint ºC 90
Nominal water flow at dT=20K m
3
/h 50,9 55,7 63,7 71,6 79,6
Hydraulic resistance at nominal flow rate kPa 58 91 60 130 165
Electrical connection V 400
Frequency Hz 50
Mains connection fuse A 16
IP class - IP00
Electrical consumption boiler max/min (without pump) W 1270/320 2330/585 2770/695
Weight (empty) kg 1369 1380 1740 1899 1991
Sound Power Level (LWA) dB 72,7
Ionisation current max/min µA 0,52
PH value condensate - 3,2
CE certification code - CE 0063CR3158
Water connections - DN80 PN16
Gas connection - DN65 PN16 DN80 PN16
Flue gas connection (DN) mm 450 500
Air intake connect. (room sealed use) (DN) mm 355
450
Condensate connection mm 40
