Elcometer 311 - Appendix 1: Summary of Gauge Icons

Icon
Description
Model
Power: Batteries - Including Battery Life Indicator
B, T
Power: USB
B, T
Bluetooth On - Grey: not paired; Orange: paired
T
F,
FNF, FNF
Substrate Type - F; Ferrous (Model B)
FNF Gauges (Auto Detect) - FNF: Ferrous; FNF: Non-Ferrous
B, T
µm
Units of Measurement - µm
B, T
mils
Units of Measurement - mils
B, T
Menu Softkey
B, T
Statistics Softkey
T
Units of Measurement Menu Option
B, T
Volume Setting Menu Option
B, T
Screen Brightness Menu Option
B, T
Legal Information Menu Option
T
Select / Set Softkey
B, T
Escape Softkey
B, T
Elcometer Contact Details Menu Option
T
