Setting the reasonable limit to 99% will switch the reasonable limit function off.
When a reasonable limit is reached for a reading value, the reading display will flash, the red LED will flash
and the beep will sound a number of times. This prompts the user to accept the reading by pressing
[ENTER] or reject the reading by pressing [DEL] (as for deletion of last reading).
7 SETUP
The setup mode enables the User to adjust a number of different functions to suit the way the instrument is
operated. The setup mode is based around 10 functions, each of which has sub-functions.
After pressing [SETUP], Function No 10 (SEL) will be displayed:
This function is used to select the Data Collection/Statistical modes, i.e. Statistics,
Average or Counted Average - see “Statistics” on page 26.
Other functions may be selected by using [<] or [>] to go through the list or by
pressing the relevant number. If [<] or [>] are pressed the individual functions are displayed and [ENTER]
must then be pressed to select that function for modification. Using the number keys, the sub-function is
more quickly selected and is thus a quick entry method for experienced users.
Once a function is entered, [<] or [>] are used to either select the alternatives, or modify the value.
Sub-functions are displayed using a second number in the ‘n’ display. e.g. ‘11’ for baud function within ‘Prnt’.
Select the required value for the function or sub-function by pressing [ENTER]. Exit the function by pressing
[0] or [SETUP] the required number of times (or [Esc]) to step back through the Sub Menus.
This display signifies the end of each menu’s options.
The following sections describe each function (in numerical order).
