Elcometer 355 User Manual

R
37
14.1 PROBE MODULES
Elcometer's unique Probe Modules allow versatile application of the Elcometer 355 Coating Thickness
Gauges. Probe Modules can be freely interchanged as required on both ferrous (F) and non-ferrous (NF)
metal substrates. Most Probe Modules are capable of an accuracy of ±1% of the reading on a variety of
coatings and surfaces.
Probe type Part number Range Accuracy Resolution in range
F1 Standard T35511952 0 µm to
1500 µm
0 mils to 60 mils
±1% or ±1 µm
±1% or ±0.04 mil
0.1 µm 0 µm to 200 µm
0.05 µm 200 µm to 500 µm
1.0 µm 500 µm to 1500 µm
0.005 mils 0 mils to 8 mils
0.02 mils 8 mils to 20 mils
0.05 mils 20 mils to 60 mils
F1 Right Angle T35511953
F1 Telescopic T35511959
F1 A
(Automotive)
T35512400
F2 Standard T35511954 0 mm to 5 mm
0 mils to 200
mils
±1% or ±5 µm
±1% or ±0.2 mil
2 µm 0 µm to 0.5 mm
5 µm 0.5 mm to 5 mm
0.1 mils 0 mils to 20 mils
0.2 mils 20 mils to 200 mils
F2 Right Angle T35511955
F2 Telescopic T35511960
F3 Standard T35511956 0 mm to 13 mm
0 mils to 500
mils
±2% or ±30 µm
±1% or ±1 mils
5 µm 0 µm to 1mm
10 µm 1 mm to 13 mm
0.2 mils 0 mils to 40 mils
0.5 mils 40 mils to 500 mils
F4 Standard T35511950 0 µm to 250 µm
0 mils to 10 mils
±1% or ±1 µm
±1% or ±0.04 mil
0.1 µm 0 µm to 250 µm
0.005 mils 0 mils to 10 mils
F4 Right Angle T35511951
