14.2 Foils
Each probe module is supplied with an appropriate set of precision foils measured using a linear
displacement transducer with an accuracy of 1% or 1 µm (whichever is the greater) of the reading.
F5 (Rebar) T35511962 0 µm to 800 µm
0 mils to 32 mils
±1% or ±2 µm
±1% or ±0.08 mil
1 µm 0 µm to 800 µm
0.1 mils 0 mils to 32 mils
F6 Standard T35511964 0 mm to 25 mm
0 mils to 1000
mils
±2% or ±100 µm
±1% or ±4 mils
10 µm 0 mm to 5 mm
50 µm 5 mm to 25 mm
0.5 mils 0 mils to 200 mils
2 mils 200 mils to 1000 mils
N1 Standard T35511982 0 µm to
1500 µm
0 mils to 60 mils
±1% or ±1 µm
±1% or ±0.04 mil
0.1 µm 0 µm to 200 µm
0.05 µm 200 µm to 500 µm
1.0 µm 500 µm to 1500 µm
0.005 mils 0 mils to 8 mils
0.02 mils 8 mils to 20 mils
0.05 mils 20 mils to 60 mils
N1 Right Angle T35511983
N2 Standard T35511984 0 mm to 5 mm
0 mils to 200
mils
±1% or ±15 µm
±1% or ±0.6 mil
2 µm 0 mm to 0.5 mm
5 µm 0.5 mm to 5 mm
0.1 mils 0 mils to 20 mils
0.2 mils 20 mils to 200 mils
N4 (Anodisers) T35511980 0 µm to 250 µm
0 mils to 10 mils
±1% or ±1 µm
±1% or ±0.04 mil
0.1 µm 0 µm to 250 µm
0.005 mils 0 mils to 10 mils
Probe type Part number Range Accuracy Resolution in range
