9 BATCHING
9.1 BATCH FUNCTIONS
The Elcometer 510 Model S gauge can store up to 60 readings in one
batch and has the following batching functions:
 Batch/New Batch; Create a new batch - see Section 9.2 for
further information.
 Batch/Open Existing Batch; Open an existing batch.
 Batch/Edit Batch/Clear Batch; Clear all readings within the
batch - but leaving all batch header information.
 Batch/Review Batch; Review the readings, statistics and batch
information - see Section 10 for further information.
 Batch/Edit Batch/Delete Batch; Delete the batch entirely from
the gauge.
 Batch/Deleted Reading/Delete without Tag; Delete the last
reading entirely.
 Batch/Deleted Reading/Delete with Tag; Delete the last reading
but mark it as deleted in the batch memory.
9.2 CREATING A NEW BATCH
Many Standards require the user to record not only the pull-off force
and the nature of the fracture but also details of the test equipment
used; if a support ring was used and its dimensions, if, and by what
means, the coating was cut around the dolly.
This additional information is recorded within the batch header and
®
transferred to PC to be included on any report within ElcoMaster . For
®
further information on ElcoMaster visit www.elcometer.com.
To create a new batch select Batch/New Batch and add the following
criteria as required:
 Dolly Size & Pull Rate;
(Batch/New Batch/Dolly Size & Pull Rate)
 Cutting Device; the type of cutting
device used, if any, to score the
coating around the dolly;
(Batch/New Batch/Cutting Device)
Batch Information
Batch 1
Created
Date Last Verified
Time Last Verified
Pull Rate
Dolly Size
Cutting Device
Skirt Type
Back
15:31 28/11/2013
25/11/2013
12:49
1.00 MPa/s
20 mm
Dolly Cutter
20 STD


