www.elcometer.com
en-18
R
®
Using ElcoMaster - supplied with each gauge, and available as a free
download at elcometer.com - gauges can transmit readings via USB to
a PC for archiving and report generation. For more information on
®
ElcoMaster visit www.elcometer.com
13 DOWNLOADING DATA
Gauge firmware can be upgraded to the latest version by the user via
® ®
ElcoMaster , as it becomes available. ElcoMaster will inform the user
of any updates when the gauge is connected to the PC with an
internet connection.
14 UPGRADING YOUR GAUGE
15 SPARES & ACCESSORIES
15.1 DOLLIES
The Elcometer 510 can be used with a range of dollies, also referred to
as test elements or stubs. 10, 14.2, 20 and 50mm diameter dollies are
d
available to purchase as an optional accessory .
10mm: ideal for testing up to 100MPa (14400psi) on very small
surface areas.
14.2mm: ideal for testing on small surface areas, for measurements
over 25MPa (3600psi) and suitable for use on some
curved surfaces.
20mm: suitable for use on a variety of coatings / substrates.
50mm: Coatings on concrete, cementitious layers and uneven
surfaces can be tested more effectively with the larger
50mm dolly. Our 50mm dollies are also available in
stainless steel as required for testing in accordance with
DIN 1048 part 2 and BS EN 12636.
Description Part Number
Aluminium Dolly 10mm (x10) T5100010AL-10
Aluminium Dolly 10mm (x100) T5100010AL-100
Aluminium Dolly 14.2mm (x10) T9990014AL-10
Aluminium Dolly 14.2mm (x100) T9990014AL-100
Aluminium Dolly 20mm (x10) T9990020AL-10
Aluminium Dolly 20mm (x100) T9990020AL-100
Aluminium Dolly 50mm (x4) T9990050AL-4
Stainless Steel Dolly 50mm (x4) T9990050SS-4
d
Please ensure the appropriate dolly skirt is fitted. See Section 6 - ‘Attaching the Gauge to the Dolly’ and
Section 15.3 - ‘Dolly Skirts’ on pages en-9 and en-19 for further information.
