Elcometer 510 User Manual

1 GAUGE OVERVIEW
1 Actuator
2 Lanyard Ring
3 Shoulder Strap Connections
4 Battery Compartment
5 LED Indicators - Red (left), Green (right)
6 Multifunction Softkeys
7 On/Off Key
8 USB Data Output Socket (below cover)
9 LCD Display
a
10 Actuator Skirt
11 Quick Connect Coupling
www.elcometer.com
en-2
R
a
The Standard Actuator Skirt for 20mm dollies is illustrated above. Skirts for other dolly sizes and thin
substrates are also available - see Section 15.3 - “Dolly Skirts” on page en-19 for details.
2
1
3
4
5
6
7
8
9
10
11
