Elcometer 510 User Manual

3 USING THE GAUGE
a
Power: Batteries - including battery life
indicator & number of pulls remaining
b
-2
Pull Rate Nmm /s - MPa/s, psi/s, N/s,
c
Dolly Size - 10mm, 14.2mm,
20mm, 50mm
d
Measurement Units - MPa, psi,
Newtons, N/mm
2
e
Start Test ( ) ; Stop Test ( ) ;
b b
Menu Softkey
f
Load Bar
g
Date & Time - when enabled and
not in batching
h
Batching On
i
Last Reading (> [greater than]
symbolizes ‘Did Not Fail’)
j
Actuator Load Value
k
User Selectable Statistics - 4 rows
l
Batch Name - when in batching
m
Run Chart - last 20 readings
(user selectable)
n
Power: USB
www.elcometer.com
en-4
R
a
b
c
h
f
g
d
e
i
j
k
l
m
n
b
is displayed when the gauge is rewinding.
4.1 FITTING THE BATTERIES
Each gauge is supplied with 16 x AA NiMH rechargeable batteries and
battery charger.
To insert or replace the batteries:
1 Unscrew the battery cap (turning
anti-clockwise) and remove the
battery cover.
2 Insert 8 batteries taking care to
ensure correct polarity.
3 Refit the cover and tighten the
battery cap.
4 GETTING STARTED
-
+
+
-
