Elcometer 510 - Warranty Statement; Technical Specification

R
www.elcometer.com
en-21
The Elcometer 510 is supplied with a 12 month warranty against
manufacturing defects, excluding contamination and wear. The
warranty can be extended to two years within 60 days of purchase via
www.elcometer.com.
17 WARRANTY STATEMENT
18 TECHNICAL SPECIFICATION
Dolly
Diameter
10mm
14.2mm
20mm
50mm
Operating
Range
8 - 100MPa
(1200 - 14400psi)
4 - 50MPa
(600 - 7200psi)
2 - 25MPa
(300 - 3600psi)
0.3 - 4.0MPa
(50 - 580psi)
Operating
Temperature
Range
-10 to 50°C (14 to 122°F); Humidity: 0 - 95% RH
Pressure
Rating
26MPa (3800psi)
Pressure
Resolution
0.01MPa (1psi)
Pressure
Accuracy
±1% of full scale
Pull Rate
Range
1.0 - 5.0MPa/s
(125 - 725psi/s)
0.4 - 2.5MPa/s
(60 - 360psi/s)
0.2 - 1.2MPa/s
(30 - 180psi/s)
0.04 - 0.20MPa/s
(5 - 30psi/s)
Pull Rate
Setting
Resolution
0.1MPa/s
(1psi/s)
0.1MPa/s
(1psi/s)
0.1MPa/s
(1psi/s)
0.01MPa/s
(0.1psi/s)
Pull Rate
Display
Resolution
0.01MPa (1psi)
Pull Rate
Accuracy
± (2.5% + 0.3 seconds) over time of test
Gauge
Memory
Up to 60 readings in one batch
Power Supply
e
8 x AA NiMH batteries
Battery Life
200 pulls per charge up to 25MPa (3600psi) at 1MPa/s (150psi/s)
e
The number of pulls remaining with a battery charge is calculated using the NiHM batteries supplied.
Alternative AA batteries (alkaline for example), can be used but will affect battery performance and the
accuracy of the “pulls remaining” indication.
