Elcometer 510 - Page 23

www.elcometer.com
en-22
R
Dolly
Diameter
10mm
14.2mm
20mm
50mm
Instrument
Weight
2.9kg (6.4lb)
2.9kg (6.4lb)
2.9kg (6.4lb)
3.1kg (8.3lb)
Kit Weight
n/a
n/a
6.1kg (13.5lb)
7.3kg (16.1lb)
Instrument
Length
260mm (10.3")
Actuator
Height
85mm (3.4")
(10mm skirt fitted)
85mm (3.4")
(14.2mm skirt fitted)
85mm (3.4")
(20mm skirt fitted)
110mm (4.3")
(50mm skirt fitted)
Can be used in accordance with:
ASTM C1583, ASTM D4541, ASTM D7234-12, AS/NZS 1580.408.5, BS 1881-207,
DIN 1048-2, EN 1015-12, EN 12636, EN 13144, EN 1542, EN 24624, ISO 16276-1,
ISO 4624, JIS K 5600-5-7, NF T30-606, NF T30-062
18 TECHNICAL SPECIFICATION (continued)
