5.2.3 SETUP PAGES MENU
First page
Second page
Third page
Fourth page
Fifth page
V
0 0 0 1 0 0
P.t. 100
A
0 0 0 0 0 5
C.t. 1.00
COG 4
Std2
Std1
m
Int 15
time
dEltA
inSErt
StAr
InSErt
SEt - UP
To access this menu, press the SEL key. To exit from this menu,
press the PAGE key for 3 seconds. To change the page, press the
PAGE key.
Use SEL and SET to select PT primary (from 1 to 999999V) and
PT secondary ( 57.7, 63.5, 100, 110, 115, 120, 173, 190, 220V).
Factory default : 100V/100V
Use SEL and SET to select CT primary (from 1 to 999999 A) and
CT secondary (from 0.01 to 1.00V).
Factory default : 1000A/1V
Press the SET key to preset the instrument for three-phase StAr
systems, three-phase DELTA systems or two phase (2 PH) systems.
Note: Delta selection forces COG4 mode and third page is hidden.
Press the SET key to preset the instrument for Standard 1 (kWh,
kVArh), Standard 2 (kWh, kVAh) or COG4 (± kWh, ± kVArh)
energy meters.
Factory default : Std1
Use the SET key to select a 1, 2, 5, 10, 15, 20, 30 or 60 minutes
integration time.
Factory default : 15 minutes
2 PH
inSErt
