25
MICROVIP3 PLUS MANUAL PRINTOUT FORMAT
Pressing "Print" button with rear
panel selector in "1-
Φ
ΦΦ
Φ
" (single-phase)
position:
Measurement page Printout format
In Pg.1,2,3,4,5,7 → V A P.F. kW
kVA kVAr Hz
+ kWh + kvarh
- kWh - kvarh
Peak kVAr Peak kVA Peak kW
(Format equivalent to Type 0 automatic printout)
plus
V and I waveforms
(Format equivalent to Type 1 automatic printout)
In Pg.6 → 1-24th Harmonics and DC
component of Voltage and Current expressed as
absolute value and in percentage referred to the
fundamental;
Total Harmonic Distortion Factors of Voltage
and Current;
Displacement Factor (Cosø of the fundamental);
Harmonics Voltage and Current bar-graph
diagram
(Format equivalent to Type 2 automatic printout)
Note: Stop Printout pressing "Print" for 5 seconds.
Pressing "Print" button with rear
panel selector in "3-
Φ
ΦΦ
Φ
" (three-phase)
position:
Measurement page Printout format
In Pg.1,4,5,6,7,8,9,12 → V A P.F. kW
kVA kVAr Hz
+ kWh + kvarh
- kWh - kvarh
Peak kVAr Peak kVA Peak kW
VL1 VL2 VL3
AL1 AL2 AL3
kW1 kW2 kW3
P.F.1 P.F.2 P.F.3
(Format equivalent to Type 0 automatic printout)
In Pg.2 → V1,V2,V3 waveforms
(Format equivalent to Type 1 automatic printout)
In Pg.3 → I1, I2, I3 waveforms
(Format equivalent to Type 3 automatic printout)
In Pg.10 → 1-24 th Harmonics and DC
component of L1, L2, L3 Voltages and
Currents expressed as absolute value and in
percentage referred to the fundamental;
Total Harmonics Distortion Factors of L1, L2,
L3 Voltages and Currents ;
L1, L2, L3 Displacement Factors (Cosø of the
fundamental) ;
L1, L2, L3 Harmonic Voltages bar-graph
diagrams
(Format equivalent to Type 2 automatic printout)
In Pg.11 → 1-24 th Harmonics and DC
component of L1, L2, L3 Voltages and
Currents expressed as absolute value and in
percentage referred to the fundamental;
Total Harmonic Distortion Factors of L1, L2,
L3 Voltages and Currents;
L1, L2, L3 Displacement Factors (Cosø of the
fundamental);
L1, L2, L3 Harmonic Currents bar-graph
diagrams
(Format equivalent to Type 4 automatic printout)
Note: Stop Printout pressing "Print" for 5 seconds.
