Configuration Screens: DISPLAY & ΔMENU
Advanced Screens: ΔMENU & DISPLAY
GO HOME: HIT RUN
HP
COMPRESS: XX
C
REFILL: FULL OUT
R
HEAD: 1/8 SS
LE
REMOTE: OFF
REM
VERSION: X.XX
V
HOME OFFSET: XX
HO
0-5V OUT: PRESS
S
STROKE: .125
ST
PRESS LIMIT: ENA
LI
Adjust
compressibility
compensation
Set refill:output
ratio
View EPROM
level
Set remote
control
configuration
Set piston &
materials of
pump
Send piston to
forward position
Set pressure
limit ON/OFF
View stroke
length
View/set
voltage out
Set home
position offset
PRESS 0: HIT RUN
XDC
Zero Pressure
Transducer
STOP STALL: ON
SS
Set motor stall
ON/OFF
ERROR DELAY: 0
ED
Set error delay
0-10 (seconds)
SAVE STATE: OFF
SP
Save OFF/ON
state
SAVE IN RUN: OFF
SR
Save flow rate
set during run
OFF/IN
REM CONTACT: OFF
RC
Use start/stop
contacts in
remote OFF/ON
