Specifications
Stainless Steel Optos/Model 1 Pump Specifications
Model
Flow Rate
Range (min.to
max.) mL/min.
Max
Pressure
(psi)
Piston
Diameter
(inches)
Max.
Piston
Stroke
Piston
Displacement
Electrical
VA
Dimensions (L x W
x H inches)
Weight
(lbs.)
1LM
0.002 - 2.5
6000
.093
.125”
.014 mL
100-230V;
50/60Hz
80
9.5 x 4 x 9
12
1LMP
0.002 - 2.5
6000
.093
.125”
.014 mL
100-230V;
50/60Hz
80
9.5 x 4 x 9
12
1SM
0.003 - 5.0
6000
.125
.125”
.025 mL
100-230V;
50/60Hz
80
9.5 x 4 x 9
12
1SMP
0.003 - 5.0
6000
.125
.125”
.025 mL
100-230V;
50/60Hz
80
9.5 x 4 x 9
12
1HM
0.01 - 20.0
3000
.250
.125”
.1 mL
100-230V;
50/60Hz
80
9.5 x 4 x 9
12
Stainless Steel Optos/Model 2 Pump Specifications
Model
Flow Rate
Range (min.to
max.) mL/min.
Max
Pressure
(psi)
Piston
Diameter
(inches)
Max.
Piston
Stroke
Piston
Displacement
Electrical
VA
Dimensions (L x W
x H inches)
Weight
(lbs.)
2LM
0.003 - 5.0
6000
.093
.250”
.028 mL
100-230V;
50/60Hz
80
9.5 x 4 x 9
12
2LMP
0.003 - 5.0
6000
.093
.250”
.028 mL
100-230V;
50/60Hz
80
9.5 x 4 x 9
12
2SM
0.01 - 10.0
6000
.125
.250”
.05 mL
100-230V;
50/60Hz
80
9.5 x 4 x 9
12
2SMP
0.01 - 10.0
6000
.125
.250”
.05 mL
100-230V;
50/60Hz
80
9.5 x 4 x 9
12
2HM
0.02 - 40.0
1500
.250
.250”
.2 mL
100-230V;
50/60Hz
80
9.5 x 4 x 9
12
Stainless Steel Optos/Model 3 Pump Specifications
Model
Flow Rate
Range (min.to
max.) mL/min.
Max
Pressure
(psi)
Piston
Diameter
(inches)
Max.
Piston
Stroke
Piston
Displacement
Electrical
VA
Dimensions
(L x W x H inches)
Weight
(lbs.)
3LM
0.01 - 10.0
3000
.093
.500”
.057 mL
100-230V;
50/60Hz
80
9.5 x 4 x 9
12
3SM
0.01 - 20.0
1500
.125
.500”
.1 mL
100-230V;
50/60Hz
80
9.5 x 4 x 9
12
3HM
0.04 - 80.0
750
.250
.500”
.4 mL
100-230V;
50/60Hz
80
9.5 x 4 x 9
12
Maximum flow rate specifications are based on the theoretical volume displacement; actual flow rates will vary depending on such factors as fluid viscosity, compressibility, and
temperature.
Common Specifications:
Wetted Parts: Type 316 stainless steel, PTFE, CTFE, sapphire, ruby
Reproducibility: ±0.3% typical
Tubing Connections: Inlet valve: ¼” –28 plastic fitting for 1/8” Teflon® tubing
Outlet valve: 1/16” I.D. ferrule and tube nut, 10-32 thread
Pumps with .250” pistons use 1/8” Swagelok style connections on the inlet and
outlet valves
Other connections available on request
Viscosity Limit: 500 Centipoise
Fuses: .8 A
Operating Environment:
Temperature: 5 – 35ºC
Maximum Humidity: 85%, non-condensing
Maximum Altitude: 2,000 meters
Optional Damper
Type: Diaphragm
Wetted Parts: Type 316 stainless steel, Kalrez
