10-4
EXPLODED VIEWS AND SPARE PARTS LISTS
Revision Y05-01
Service Manual - DNC Series
10.4 Indoor Unit: DNC 35, 35T
Draw. No. Part No. Name Qty. Rev.
1 433477 Mounting Plate 1 1
2 SP000000095 Insulated side wall 2 1
3 433320 Adapter 8" 3 1
4 SP000000096 Drain pump assembly 1 1
5 433326 Nipple 1 1
6 433478 Hanging track 2 1
7 402713 Wire display box 1 1
8 402730 Cable 8 wires 7m with connectors
1 1
9 SP000000097 Electrical box assembly 1 1
11 SP000000098 Drain pool assembly 1 1
12 SP000000099 Air inlet assembly 1 1
13 433315 Filter 1 1
14 433324 Return air grill assembly 1 1
15 433397 Carbon filter 2 1
16 438600 Remote control RC RC3 1 1
17 SP000000101 Coil assembly 1
18 433318 Coil support 2 1
19 433306 Fan 1 1
20 433316 Bracket 4 1
21 433322 Adapter 12" 1 1
22 433335 Adapter 12" cover 1 1
23 433321 Adapter 10" 1 1
24 433386 Manual damper 1 2
25 433417 Motor 1 2
26 433314 Air connector 1 1
To Next Page
