Electra DNC series - INSTALLATION MANUAL; Accessories Provided with Air-Conditioner

INSTALLATION MANUAL
English 1
1. List of accessories provided with the air-conditioner
Description Amount Name Use
1 Technician’s installation
manual
Installation instructions
Instruction manual for
remote control
Operation instructions for remote
control
1 Instruction manual for the
user
Operation instructions
1 Remote control including
batteries
Operating the air-conditioner
1 Remote control bracket
Hanging the remote control on the
wall
1 Central control display
Operating and main working regime
display
2 Carbon filter
Air cleaning
4 Rubber mounting pads
Padding of the outdoor unit
4 Tie - Wraps
Tightening the indoor and the outdoor
units electrical cables
4 Washer for hanging the
indoor unit
Securing the location of the pole in
the ear on which the unit is hanging
1 Mounting plate
Hanging the unit
2 Hanging tracks
Hanging the unit
6 Machine screws for
hanging tracks
Installing hanging tracks
6 Spring washer for
hanging tracks
Installing hanging tracks
6 Screws for installing
adapters
Securing installment of adapters
4 10” adapter screws
Installing 10” adapters
4
4
4
Dibbles
Screws
Washers
Installing bracket for remote control
and central control display
4 8” adapter
Mounting a flexible 8” diameter duct
1 12” adapter
Mounting a flexible 12” diameter duct
1 10” adapter
Mounting a flexible 10” diameter duct
