Electra DNC series - Page 110

10-7
EXPLODED VIEWS AND SPARE PARTS LISTS
Revision Y05-01Service Manual - DNC Series
10.7 Outdoor Unit: OU8-33 RC => R22
Draw.No. Part No. Name Qty. Rev.
1 437045 LARGE UPPER COVER OU 1 4
2 402930 SIDE PANEL OU8-33 1 1
3 436357 SMALL ELECTRICAL COVER OU 1 3
4 402928 FRONT PANEL OU8-33 1 1
5 437091 OU SQUARE FAN GUARD 1 2
6 434802 BASE ASS.OU12-60T/180T 1 4
7 402944 COIL OU8-33 HDR 1 1
8 402937 AXIAL FAN D490*143.5 1 1
9 402936 MOTOR 89W,2S,OU8-33 1 1
10 402929 NET SIDE PANEL OU8-33 1 1
11 436358 OU LEADING HANDLE 1 2
12 439775 MOTOR SUPPORT OU8-33 1 1
14 439774 COMPRESSOR SQ040PAB 1 1
15 439785 CAPILLARY ASSY OU8-33 R22 1 1
16 439791 TUBING ASSY OU8 1 1
17 402495 BOARD TPHN 5B 1 1
18 442371 CAPACITOR 400V 6mF 1 2
19 434716 THERMISTOR+CAP WTH CONNECTOR L1050 1 1
20 442001 CAPACITOR 400V 60mF 1 1
21 442457 VALVE COIL SANHUA MOLEX 1 1
22 402012 SUCTION ACCUMULATOR 3*5/8 3.5Lb 1 2
23 439656 SIDE COVER OU10 1 2
26 430376 COMPRESSOR WIRING WTH PLUG+CONNECTOR 1 1
28 190441 HEATER CRANKCASE OU8 LG 1 1
