10-13
EXPLODED VIEWS AND SPARE PARTS LISTS
Revision Y05-01Service Manual - DNC Series
10.13 Outdoor Unit: OU10-38 RC => R22
Draw.No. Part No. Name Qty. Rev.
1 437045 LARGE UPPER COVER OU 1 4
2 439655 SIDE PANEL OU10 1 3
3 439656 SIDE COVER OU10 1 2
4 439653 FRONT PANEL OU10 1 3
5 439662 GRILLE OU10 2 1
6 439833 NEW BASE ASSY OU 1 1
7 439755 COIL OU10-38 1 1
8 439650 AXIAL FAN D400*112 2 1
9 439651 MOTOR 70W,3S,OU10 2 2
10 439654 NET SIDE PANEL OU10 1 3
11 436358 OU LEADING HANDLE 1 1
12 439657 MOTOR SUPPORT OU10 1 2
13 436357 SMALL ELECTRICAL COVER OU 1 3
14 402792 COMPRESSOR ZR47K3-PFJ-601 1 1
15 439754 CAPILLARY ASSY OU10-38 1 1
16 439695 TUBING ASSY OU10-38 1 1
17 402495 BOARD TPHN 5B 1 1
18 442378 CAPACITOR 400V 3mF 2 2
19 434716 THERMISTOR+CAP WTH CONNECTOR L1050 1 1
20 442001 CAPACITOR 400V 60mF 1 1
21 442462 VALVE COIL L700 4-WAY MOLEX 1 1
22 435875 COMPRESSOR WIRING WTH PLUG L1100 1 1
23 439661 CONES OU10 2 1
24 402189 SUCTION ACCUMULATOR 5" x 3/4" 7Lb 1 1
26 436352 RAISING HANDLE OU10 1 1
28 190441 HEATER CRANKCASE OU8 LG 1 1
