PRODUCT DATA SHEET
Revision Y05-01Service Manual - DNC Series
DNC 1155 R407C
Model
Ceiling Mounted
Installation method
HeatingCoolingUnits
Characteristic
3800035000Btu/hr
1110010300W
Capacity
39853950WTotal input
2.762.6W/W COP
230V/50Hz/1Power supply (voltage, cycle,No of phases)
17.317.2ARated current
25ACircuit breaker rating
Plug Fan x 1 Fan type & qty.
500 550 700 RPM Fan speed (HI-M-LO)
120013301700m³/hr
7057801000CFM
Airflow (LO-M-HI)
20-80PaStatic Pressure
54.85657.2dBANoise Power**
47.549.751.8dBANoise Pressure*
3.5l/hDehumidification
16mmCondensate drain tube I.D
1025mmWDimensions
760mmD
300mmH
44KgWeight
1125x975x360(Unit)+1180x870x180(Frame)mmPackage dimensions
7units Stacking height
7units Units per palet
I
N
D
O
O
R
U
N
I
T
Capillary TubeRefrigerant control
SCROLL ZR47KCE-PFJCompressor type & model
Axialx2 Fan type & qty.
1125RPM Fan speeds
4150m³/hr
2440CFM
Airflow (std. conditions)
57/65dBANoise Pressure*/ Noise Power
900mmWDimensions
340mmD
970mmH
95KgWeight
1020x985x406 mmPacking dimensions
2units Stacking height
6units Units per palet
R 407CRefrigerant
Charge for 7.5 meter pipes length
O
U
T
D
O
O
R
U
N
I
T
16mmCondensate drain tube I.D
3/8”in.liquid
3/4”in.suction
25mheight differenceConnection between units
50mtubing length
T
U
B
E
S
LCD Remote ControlOperation control type
2x1500 WHeating elements
8”,10”,12” Ducts
Crankcase heater 33W Others
A
C
C.
* Noise pressure tested at 1m distance from unit
** Noise power for ducted units measured at air outlet side
Grams
2400
