EXPLODED VIEWS AND SPARE PARTS LISTS
Revision Y05-01Service Manual - DNC Series
10.21 Outdoor Unit: OU10-50 ST => R407C
Draw.No. Part No. Name Qty. Rev.
1 437045 LARGE UPPER COVER OU 1 4
2 439655 SIDE PANEL OU10 1 3
3 439656 SIDE COVER OU10 1 2
4 439653 FRONT PANEL OU10 1 3
5 439662 GRILLE OU10 2 1
6 439841 NEW BASE ASSY OU EL 1 1
7 439744 COIL GR/HDR OU10-50 1 1
8 439650 AXIAL FAN D400*112 2 1
9 439651 MOTOR 70W,3S,OU10 2 2
10 439654 NET SIDE PANEL OU10 1 3
11 436358 OU LEADING HANDLE 1 1
12 439657 MOTOR SUPPORT OU10 1 2
13 436357 SMALL ELECTRICAL COVER OU 1 3
14 439767 COMPRESSOR HR061YAA LG 1 1
15 402250 CAPILLARY ASSY OU10-50 ST 1 1
17 402453 BOARD TPHN 3B 1 1
18 442378 CAPACITOR 400V 3mF 2 2
19 434716 THERMISTOR+CAP WTH CONNECTOR L1050 1 1
22 435545 COMPRESSOR WIRING WTH PLUG L1200 3PH LG 1 1
23 439661 CONES OU10 2 1
24 402189 SUCTION ACCUMULATOR 5" x 3/4" 7Lb 1 1
25 439795 BOARD 3PH PROTECTOR 1 1
26 436352 RAISING HANDLE OU10 1 1
27 402741 THERMISTOR WTH CONNECTOR L1250 1 1
28 190442 HEATER CRANKCASE OU10 LG 1 1
