PERFORMANCE DATA & PRESSURE CURVES
Revision Y05-01 Service Manual - DNC Series
DNC 1255 - R407C HEATING SUCTION PRESSURE
1.00
1.50
2.00
2.50
3.00
3.50
4.00
4.50
5.00
5.50
6.00
-5 0 5 10 15
Outdoor Temp. (C DB)
SUCTION PRESSURE [Bar(g)]
20 C DB
18 C DB
15 C DB
Indoor Temp.
DNC 1255 - R407C HEATING DISCHARGE PRESSURE
13
15
17
19
21
23
-5 0 5 10 15
Outdoor Temp. (C DB)
DISCHARGE PRESSURE [Bar(g)]
20 C DB
18 C DB
15 C DB
Indoor Temp.
