14-10
EXPLODED VIEWS AND SPARE PARTS LISTS
Revision Y05-03 Service Manual - WNG
14.1.10 Indoor Unit WNG 18, 24 LED
NO. Part No. Description Quantity
1A 452917400 Grill A/WNG18 1
1B 452952800 Grill B/WNG18 1
1C 452952900 Grill C/WNG18 1
2 453024600 LED Display Assy. 1
3 452919800 Filter 2
4 4518113 Fiber Filter Assy. (Optional) 1
5 453054000 Frame assy./WNG18 1
6 4527144 Display Cover Assy 1
7 452919600 Screw cover 3
8 433133 IONIZER DISPLAY 906-191-07 (Optional) 1
8A 452919700 Cover/Ionizer (Optional) 1
9 453046600 Evaporator (WNG18) 1
453055200 Evaporator (WNG24) 1
10 4518664 Drain hose 1
11 452917300 Air outlet 1
12 452918700 Support/horizontal louver 2
13 452917500 Horizontal flap A 1
14 452917600 Horizontal flap B 1
15 452918500 Linkage A 1
452918600 Linkage B 1
16 452930700 Vertical flap A 12
452918200 Vertical flap B 2
17 452918300 Tie/vertical flap A 1
452918400 Vertical flap stator B 2
452953000 Vertical flap stator C 1
18 4518662 Bearing assy fan 1
19 453024900 Impeller fan 1
20 453053800 Base assy./WNG18 1
21 4518657 TUBE LOCK 1
22 452920100 Mount bracket/WNG-18/20 1
23 452919400 Joint/Unit housing 1
24 453116500 Resin Motor 20W/WNG18 LED 1
453134300 Resin Motor 26W/WNG24 LED 1
25 4518651 Cover Side Motor 1
26 452918800 Cover/motor 1
27 4521197 Remote controller RC3 1
28 453050300 STEP MOTOR B 1
29 453057900 Gear BOX ASSY 1
30 4526201 IONIZER CABLE B (Optional) 1
31 433134 IONIZER POWER 906-191-01 (Optional) 1
32 453131500 Power Cord 16A/ British-TypeCables & Power cords. 1
33 4524967 IONIZER WIRE A (Optional) 1
34 453116400 WNG 18 LED Controller EHK P/N 916-255-18 1
35 4524963 Electrostatic Filter (Optional) 1
36 452919500 Cover/terminal 1
