14-11
EXPLODED VIEWS AND SPARE PARTS LISTS
Revision Y05-03Service Manual - WNG
14.1.11 Indoor Unit WNG 21 LED
No. Item Code Item Desc Qty
8 433133 IONIZER DISPLAY 906-191-07 1
31 433134 IONIZER POWER 906-191-01 1
4 4518113 AIR FILTER ASSY 1
25 4518651 Cover Side Motor 1
21 4518657 TUBE LOCK 1
18 4518662 Bearing assy fan 1
10 4518664 Drain hose 1
35 4524963 Electrostatic Filter 1
30 4524967 IONIZER WIRE A 1
33 4526201 IONIZER CABLE B 1
6 4527144 (LED) Display Cover Assy 1
27 4527178 RC 7 1
13 452917500 Horizontal flap A 1
14 452917600 Horizontal flap B 1
17 452918300 Tie/vertical flap A 1
15 452918500 Linkage A 1
12 452918700 Support/horizontal louver 1
26 452918800 Cover/motor 1
23 452919400 Joint/Unit housing 1
36 452919500 Cover/terminal 1
7 452919600 Screw cover 3
3 452919800 Filter 2
22 452920100 Mount bracket/WNG-18 1
16 452930700 Vertical flap A 12
1 452952900 Grill A/WNG18 1
2 453024600 LED Display Assy. 1
19 453024900 Impeller fan 1
28 453050300 STEP MOTOR B 1
20 453053800 Base assy./WNG18 1
11 453053900 Air outlet assy./WNG18 1
5 453054000 Frame assy./WNG18 1
29 453057900 Gear BOX ASSY 1
34 453116400 WNG 18 LED EHK P/N 916-255-18 1
None 453116400 WNG 18 LED EHK P/N 916-255-18 1
None 453116400R WNG 18 LED EHK P/N 916A255-18 1
24 453134300 Resin Motor 26W 1300/1200/ 1100 1
32 453232400 Power Cord Without Plug/ E 1
9 453260400 Evaporator Assy/WNG24 1
