Electro-Voice EVOLVE 50 - Technical Data; Dimensions and Weights

Technical data
Frequency Response (-3 dB): 43 Hz – 20 KHz
1
Frequency Range (-10 dB): 37 Hz – 20 KHz
1
Maximum SPL: 127 dB
2
Coverage (H x V): 120° x 40°
Amplifier Rating: 1000 W
LF Channel Rating: 500 W
HF Channel Rating: 500 W
Crossover Frequency: 200 Hz
Connectors: 2x XLR/TRS Combo Jack Input
1x 3.5 mm Input
1x Stereo RCA Input
1x Wireless Bluetooth® Audio Input
1x XLR THRU Output
1x XLR MIX OUT Output
Enclosure: Sub: 15 mm plywood
Column: Composite
Pole: Aluminum
Grille: Steel with black powder coat
Color: Black
Dimensions (HxWxD):
mm (in)
Sub: 530 x 345 x 471 (20.9 x 13.6 x 18.5)
Column: 825 x 102 x 172 (32.5 x 4.0 x 6.9)
Pole: 929 x 48.5 x 55 (36.6 x 1.9 x 2.2)
Net Weight: Sub: 44.66 lb (20.3 kg)
Column: 10.34 lb (4.7 kg)
Pole: 2.75 lb (1.25 kg)
Sub cover: 0.9 lb (0.4 kg)
Bag for column and pole:1.87 (0.85 kg)
Shipping Weight: Sub box: 50.71 lb (23 kg)
Column box: 18.30 lb (8.3 kg)
Power Consumption: 100 - 240 V AC, 50 - 60 Hz, 1.5 - 0.6 A
3
1
Full space measurement using music DSP preset.
2
Maximum SPL is measured at 1 m using broadband pink noise at maximum output.
3
Current rating is 1/8 power.
9
en 25
Electro-Voice Installation manual 2017.07 | 02 | F.01U.341.640
