18
ARCHIMEDE LCD SERIES - ENG
ELECTROIL
13
A group of two or more
inverters cannot
communicate between each
other in Master-Slave mode
For the BC inverters type read on left.
For the RS type check the correct connection RS485 by a two wires cable (A
to A and B to B).
Verify the communication set to Master-Slave on Advanced Functions ->
Group Functioning (code 0 for the inverter Master, code 1, 2, etc for all the
others Inverters Slave)
14
The Inverter conduct on the
input voltage supply line
electromagnetic noises that
disturb other electronic
devices
Check Ground cable connections (Ground system must be radial type, with
resistance less than 10 Ohm).
All the Inverters have an internal Input EMC filtering stadium, but is available
also an additional EMC Input filter (various types, contact the service) for
bigger noise suppression with sensitive devices connected on the line.
15
With a long cable between
Inverter and Motor
sometimes the inverter stop
the motor in Pick Current
alarm
The motor can have high pick voltage value caused by the high frequency of
the PWM combined with the high capacitance to ground of the long cable: we
suggest to use an additional inverter output filter for cable longer than 40
meters connecting it directly on the Inverter output. Available various types of
output filters, contact the service to receive informations.
16
The Differential Circuit
Breaker on the line
sometimes switch off the
inverter
Check the Ground system resistance (must be less than 10 Ohm).
Use only differential circuit breaker type A (specific for Inverters).
17
The Magneto-Thermal
Circuit Breaker on the line
switch off the inverter when
the pump run at the
maximum power
All the inverters may have a high pick value of the sinusoidal caused by the
harmonics (5
th
, 7
th
, 11
th,
etc.) and depending by the resistance of the line, but
this condition don’t increase the energy absorbing value depending by the area
under this current curve. Only you need to use a Magneto-Thermal Circuit
Breaker with a higher Current value than the value that you can use for the
direct pump controlled. Usually it’s enough a switch one step higher than the
switch useful for the simple motor (see table of the Magneto-Thermal
protection suggested on the handbook).
Table 8: Solution of the most common installation and working problems
8 GUARANTEE
Under the current European low: guarantee of 2 years calculated from the date of delivery of prejudice further provisions
of law or contract.
To have service in guarantee, it must submit to the company providing the guarantee certificate completed.
The guarantee is excluded or interrupted in anticipation if the damage is caused to the following:
External influences, non-professional installation, non-compliance with instructions, interventions by unauthorized
locations, use of not original spare parts and normal wear.
