Electrolux CLAI1G Installation Manual

13
Legend
A
Type of appliance
• Under counter dishwasher
B
Rinsing type
• 0 = without rinse pump
• 1 = with rinse pump
C
Water treatment
• 0 = without water softener [WS]
• 1 = with water softener [WS]
C.6 Responsibility
The Manufacturer declines any liability for damage and
malfunctioning caused by:
• non-compliance with the instructions contained in this
manual;
• repairs not carried out in a workmanlike fashion, and
replacements with parts different from those specified in
the spare parts catalogue (the fitting and use of non-original
spare parts and accessories can negatively affect appliance
operation and invalidates the original manufacturer
warranty);
• operations carried out by non-specialised personnel;
• unauthorized modifications or operations;
• missing, lack or inadequate maintenance;
• improper appliance use;
• unforeseeable extraordinary events;
• use of the appliance by uninformed and / or untrained
personnel;
• non-application of the current provisions in the country of
use, concerning safety, hygiene and health in the workplace.
The Manufacturer declines any liability for damage caused by
arbitrary modifications and conversions carried out by the user
or the Customer.
The employer, workplace manager or service technician are
responsible for identifying and choosing adequate and suitable
personal protection equipment to be worn by operators, in
compliance with regulations in force in the country of use.
The Manufacturer declines any liability for inaccuracies con-
tained in the manual, if due to printing or translation errors.
Any supplements to the installation, use and maintenance
manual the Customer receives from the Manufacturer will form
an integral part of the manual and therefore must be kept
together with it.
C.7 Copyright
This manual is intended solely for consultation by the operator
and can only be given to third parties with the permission of
Electrolux Professional company.
C.8 Keeping the manual
The manual must be carefully kept for the entire life of the
appliance, until scrapping. The manual must stay with the
appliance in case of transfer, sale, hire, granting of use or
leasing.
C.9 Recipients of the manual
This manual is intended for:
• the carrier and handling personnel;
• installation and commissioning personnel;
• specialised personnel - Customer Care service (see service
manual).
D TECHNICAL DATA
D.1 Main technical characteristics for single phase appliances
Model
ELAI1G
CLAI1G
ELAI1GCL
ELAI1WG
NLAI1WG
ELAI1G8
VLAI1G8
ELAI1G4
VLAI1G4
ELI1G36M
Supply voltage:
230V 1N~ 230V 1N~ 230V 1N~
208V 1~
33 amp
240V 1~
29 amp
230V 1N~
Convertible to:
400V 3N~
230V 3~
400V 3N~
230V 3~
400V 3N~
230V 3~
208V 3~
20 amp
240V 3~
18 amp
400V 3N~
230V 3~
Minimum Supply - Circuit
Ampacity
- - -
34 amp 34 amp
-
Frequency
Hz 50 50 50 60 50 60
Max. power
kW
5.35 [7.35]
1
6.85 [8.85]
1
5.35 [7.35]
1
6.85 6.85
6.85 [8.85]
1
Boiler [booster]
heating elements
kW 4.5 6 4.5 6.0 6.0 6
Tank heating
elements
kW 2.0 2.0 2.0 2.2 2.2 2.0
Water supply
pressure
bar
[kPa]
(psi)
0.5 - 7
[50 - 700]
0.5 - 7
[50 - 700]
0.5 - 7
[50 - 700]
0.5 - 7
[50 - 700]
(7.25 - 101)
0.5 - 7
[50 - 700]
(7.25 - 101)
2 - 3
[200 - 300]
Water supply
temperature
℃
[℉]
50
[122]
50
[122]
50
[122]
10 - 50
[50 - 122]
10 - 50
[50 - 122]
50
[122]
Water supply
hardness
°f/°d/°e
[ppm]
14/8/10
max
14/8/10
max
48/27/33.7
max
14/8/10 max
[140]
14/8/10 max
[140]
14/8/10 max
Electric conduc-
tivity of water
μS/cm
[μS/in]
< 400 < 400 < 400
< 400
[< 1016]
< 400
[< 1016]
< 400
Concentration of
chlorides in
water
ppm
< 20 < 20 < 20 < 20 < 20 < 20
