18
• Lift the equipment with a lift truck, remove the base and
position it the place of use.
• Carefully remove the protective film from the outer panels
without tearing it, to avoid leaving traces of glue.
• Adjust the equipment by turning the special adjustable feet
and making sure it is perfectly level, both length wise and
crosswise.
• If the dishwasher is installed under a work plan, the
dimensions of the space, where it is inserted, must be the
same as those shown in the following figure. Position the
dishwasher and level the appliance by turning the relative
height-adjustable feet.
CAUTION
During the washing cycles, small amounts
of steam may escape from the dishwasher
door. Protect all unsuitable materials
exposed to the dishwasher steam and
detergents. If you must insert the dish-
washer under a work plan, make sure to
shield all surfaces close to the dishwasher
with materials resistant to moisture and
steam.
• If the dishwasher is installed on a special support (eg.: work
plan), follow these steps:
1. Accessing the appliance bottom panel and unscrew the
4 feet.
2. Make 4 holes ⌀ = 9 mm on the support respecting the
distances shown in the figure below.
3. Put the dishwasher on the support by matching the
holes just made with the seats of the feet in the
appliance bottom panel (see following figure).
4. Fix the dishwasher steadily using screws M8.
F.5 Disposal of packing
The packing must be disposed of in compliance with the
current regulations in the country where the appliance is used.
All the packing materials are environmentally friendly.
They can be safely kept, recycled, or burned in an appropriate
waste incineration plant. Recyclable plastic parts are marked
as follows:
Polyethylene
• Outer wrapping
• Instructions bag
Polypropylene
• Straps
Polystyrene foam
• Corner protectors
The parts in wood and cardboard can be disposed of,
respecting the current regulations in the country where the
appliance is used.
