Model ELAI3GTL ELAI3GCL ELAI3GWL
EUCA060
VUCA060
ZUCA060
ELAI3PML
ELAI3WGML
ET5AI ET5AIP
Standard cycle
time with water
supply at 50℃
[122℉].
4
sec.
90 - 120 -
240
90 - 120 -
240
90 - 113 - 173
90 - 120 - 240
3
[90 - 240]
5
90 - 120 -
120
90 - 120 - 120
Legal noise level
Leq
6
dB(A) LpA: 61dB - KpA: 1.5dB
Protection rating
IPX4
Power supply cable
H07RN-F
1. If activated by software, coincidence of tank and boiler heating elements.
2. Only for model ELAI3WGML
3. Disinfection cycle.
4. Standard cycle time may vary should the inlet water temperature and/or the boiler heating elements be different from that indicated above.
5. Only for model VUCA060
6. The noise emission values have been obtained according to EN ISO 11204.
D.3 Characteristics of power supply cable
400 - 440V 3~ 380 - 415V 3~N 220 - 240V 3~ 220 - 240V 1~N
C S C S C S C S
5.35 kW 4x2,5 mm
2
16A 3P 5x2,5 mm
2
16A 3P + N 4x4 mm
2
20A 3P 3x6 mm
2
30A 1P + N
6.85 kW 4x2,5 mm
2
16A 3P 5x2,5 mm
2
16A 3P + N 4x4 mm
2
20A 3P 3x6 mm
2
40A 1P + N
7.35 kW 4x2,5 mm
2
16A 3P 5x2,5 mm
2
16A 3P + N 4x4 mm
2
25A 3P 3x10 mm
2
40A 1P + N
8.85 kW 4x2,5 mm
2
16A 3P 5x2,5 mm
2
16A 3P + N 4x4 mm
2
32A 3P 3x10 mm
2
50A 1P + N
9.35 kW 4x2,5 mm
2
20A 3P 5x2,5 mm
2
20A 3P + N 4x6 mm
2
32A 3P 3x10 mm
2
50A 1P + N
11.85 kW 4 4 mm
2
32A 3P 5x4 mm
2
25A 3P + N 4x8 mm
2
40A 3P 3x16 mm
2
63A 1P + N
C = Power supply cable
S = On/Off switch
D.4 Characteristics of power supply
The AC power supply to the machine must meet the following conditions:
• max. voltage variation ± 6%
• max. frequency variation ± 1% continuous ± 2% for a short period.
Harmonic distorsion, unbalanced three-phase supply voltage, voltage pulses, interruption, dips and the other electric character-
istics must respect the provisions of point 4.3.2 of Standard EN 60204-1 (IEC 60204-1).
E TRANSPORT, HANDLING AND STORAGE
WARNING
Refer to “Safety Information“.
E.1 Introduction
Transport (i. e. transfer of the appliance from one place to
another) and handling (i. e. transfer inside workplaces) must
occur with the use of special and adequate means.
CAUTION
The appliance must only be transported, handled and
stored by specialised personnel, who must have:
• specific technical training and experience in the use of
lifting systems;
• knowledge of the safety regulations and applicable laws
in the relevant sectors;
• knowledge of the general safety rules;
• personal protection equipment suitable for the type of
operation carried out;
• the ability to recognize and avoid any possible hazard.
E.2 Transport: Instructions for the carrier
IMPORTANT
The transported load can shift:
• when braking;
• when accelerating;
• in corners;
• on rough roads.
E.3 Handling
Arrange a suitable area with flat floor for appliance unloading
and storage operations.
E.3.1 Procedures for handling operations
Before lifting:
• send all operators to a safe position and prevent persons
from entering the handling area;
• make sure the load is stable;
• make sure no material can fall during lifting. Manoeuvre
vertically in order to avoid impacts;
• handle the appliance, keeping it at minimum height from the
ground.
To Next Page
