Electrolux CLAI1G Installation Manual

15
Model
ELAI3...
ZLAI3...
NLAI3...
VLAI3...
XLAI3...
DW6-38
ELI3
ZLI3
ELI3CG
ZLI3CD
ELAI3WP
ZLAI3WP
ZLAI3WG
ELI3G5M
ELI3G35M
ELI3G6M
ELAI3-
GUSPH6
ELAI3-
GUSPH5
Tank capacity
l 23 23 23 23 23 23
Standard cycle
time with water
supply at 50℃
[122℉].
9
sec.
90 - 120 -
240
90 - 120 -
240
90 - 120 - 240 90 - 120 - 240
90 - 120 -
240
90 - 120 - 240
[90 - 180]
10
[120 - 180 -
240]
7
Legal noise level
Leq
11
dB(A) LpA: 61dB - KpA: 1.5dB
Protection rating
IPX4
Power supply cable
H07RN-F
1. Only for model ZLI3CD
2. Only for model ELI3G35M
3. Only for model ELAI3GUSPH5
4. Only for model ELAI3P6
5. If activated by software, coincidence of tank and boiler heating elements.
6. Only for model NLAI3CG
7. Only for models ELAI3GUSPH5 and ELAI3GUSPH6
8. Only for model NLAI3CG
9. Standard cycle time may vary should the inlet water temperature and/or the boiler heating elements be different from that indicated above.
10. Only for model VLAI3G
11. The noise emission values have been obtained according to EN ISO 11204.
Model ELAI3GTL ELAI3GCL ELAI3GWL
EUCA060
VUCA060
ZUCA060
ELAI3PML
ELAI3WGML
ET5AI ET5AIP
Supply voltage:
400V 3N~ 400V 3N~ 400V 3N~ 400V 3N~ 400V 3N~ 400V 3N~
Convertible to:
230V 3~
230V 1N~
230V 3~
230V 1N~
230V 3~
230V 1N~
230V 3~
230V 1N~
230V 3~
230V 1N~
230V 3~
230V 1N~
Frequency
Hz 50 50 50 50 50 50
Max. power
kW
5.35 [7.35]
1
9.85 [11.85]
1
6.85 [8.85]
1
6.85 [8.85]
1
8.85 6.85
Boiler heating
elements
kW 4.5 9 6 6 6 6
Tank heating
elements
kW 2.0 2.0 2.0 2.0 2.0 2.0
Water supply
pressure
bar
[kPa]
0.5 [50]
7 [700]
0.5 [50]
7 [700]
0.5 [50]
7 [700]
0.5 [50]
7 [700]
2 [200]
3 [300]
0.5 [50]
7 [700]
Water supply
temperature
℃
[℉]
50
[122]
50
[122]
50
[122]
50
[122]
10
[50]
10
[50]
Water supply
hardness
°f/°d/°e
14/8/10
max
14/8/10
max
14/8/10 max
14/8/10 max
[48/27/33.7
max]
2
14/8/10 max 14/8/10 max
Electric conduc-
tivity of water
μS/cm
< 400 < 400 < 400 < 400 < 400 < 400
Concentration of
chlorides in
water
ppm
< 20 < 20 < 20 < 20 < 20 < 20
Hot rinse cycle
water
consumption
l
3 (for wash
cycle 1)
3.5 (for
wash cycle
2)
4 (for wash
cycle 3)
2.5 3.8
3 (for wash
cycle 1 and 2)
4 (for wash
cycle 3)
3
3 3
Cold rinse cycle
water
consumption
l 1.8
- - - - -
Boiler capacity
l 12 12 12 12 12 12
Tank capacity
l 23 23 23 23 23 23
