Electrolux COOKING - Pyrolytic Cleaning Explanation

- 8 -
DGS-TDS-N 05.09 A. B. © Electrolux 599 521 367 EN
100
200
300
400
500
min
° C
P1P2P3
90 120
150
Fig. heating-up curve temperature (°C) / time (min
With the Pyroluxe self-cleaning system the residues in the interior are carbonized to ashes at high
temperatures. The centre of gravity temperature of the muffle is approx. 500°C.
A max. selection of three pyrolysis durations (P…) can be made per appliance class and
equipment.
Pyrolysis duration (Heating period)
P1 > Heating period 150min
P2 > Heating period 120min
P3 > Heating period 90min
Note: In appliances which are equipped with two pyrolysis durations, P2 corresponds to the
pyrolysis duration P3.
3.2 Pyrolitical cleaning - Explanation
end of heating phase
cooling phase
door locked
door unlocked
room temperature
