Electrolux EOC617 - Installation

WARNING
warning
USE AN AUTHORISED PERSON
As stated in the local municipal building codes and other relevant
statutory regulations.
• WiringconnectionsmustbeinaccordancewithAS/NZS
3000 Wiring Rules and any particular conditions of the
local authority.
• Refertodataplateforratinginformationandcircuitdiagram.
The data plate is positioned behind the bottom of the oven
door. The circuit diagram is positioned on the top panel of
the appliance.
• Anallpoledisconnectfunctionalswitchshouldbeprovided
near the appliance in an accessible position. Refer to AS/
NZS 3000 clause 4.3.11
• Wiringshouldbeprotectedagainstmechanicalfailure.
Refer to AS/NZS 3000 clause 3.9
• Ameansofdisconnectionwithacontactseparationofatleast
3mm must be supplied in the fixed wiring.
• Togainaccesstothemainsconnectionterminals,remove
the rear panel by unscrewing the 2 assembly screws.
NOTE:Whereconnectionismadetoamulti-phase240V
supply,thebridgepieceshouldberemovedfrombetween
theactiveconnections.
WARNING
warning
IMPORTANT: This appliance must be properly earthed.
• Donotlifttheappliancebythedoorhandles.
• Preparethecupboardopeningtomatchyourappliance
measurements. (See diagrams)
• Slideapplianceintothecupboard,ensuringthatthesupply
cable (where fitted) does not kink.
• Topreventtipping,usethescrewssuppliedtosecureyour
oven into the cupboard. Use just 2 screws for single cavity
ovens and 4 screws for dual cavity. Remove the bottom
door in dual cavity ovens to provide access to the bottom
2 screwing points. (See illustration page 23)
• Forappliancesttedwithasupplyexiblecord,ifthecord
is damaged, it must be replaced by the manufacturer or its
service agent or similarly qualified person in order to avoid
a hazard. The plug must be accessible after installation.
• Wheretheapplianceisbuiltintoacabinet,thecabinet
material must be capable of withstanding 70°C. Installation
into low temperature tolerant cabinetry (e.g. vinyl coated)
may result in deterioration of the low temperature coating by
discolouring or bubbling.
• Iftheapplianceisinstalledadjacenttovinyl-wrappedsurfaces,
use an installation kit available from the vinyl-wrap supplier.
• ElectroluxHomeProductscannotacceptresponsibility
for damage caused by installation into low temperature
tolerant cabinets.
• Afterinstallation,testandensurethattheapplianceoperates
correctly before handing it over to the customer.
WARNING
warning
CAUTION:Toavoidanypotentialhazard,youmustfollowour
instructionsbelowwhenyouinstallyourappliance.Failureto
installtheappliancecorrectlycouldinvalidateanywarranty
orliabilityclaimsandleadtoprosecution.
installation
22 INSTALLATION Built-in Cooking
