7 CYCLE SETTING
IIn this paragraph is explained how to change cycle phases duration (see paragraph 7.1 CYCLE DIAGRAM).
• Switch on the dishwasher;
• Enter into the FACTORY SETTING mode: press and hold down ON/OFF and CYCLE_2 keys for at least 5
seconds (Figure 43);
• Press CYCLE_2 key to select CYCLE_1 parameters.
• Press CYCLE_INFINITE. The display shows alternatively the symbol
 (Figure 46) and the corre-
sponding value
 (Figure 47);
• Use CYCLE_1 key to increase the value and CYCLE_2 key to decrease (Figure 47);
• Press CYCLE_INFINITE key to confirm
. The display shows the next parameter (Figure 48) and the corre-
sponding value (Figure 49);
• In the same way is possible to change the other parameters;.
After settled all parameters referring Cycle 1, by pressing CYCLE_2 key is possible to change the Cycle 2
parameters (Figure 50), (Figure 51) and so on.
Fig. 43 Factory setting
mode.
Fig. 44 Select next class. Fig. 45 Cycle 1 Family:
ENTER.
Fig. 46 Wash duration [min].
Fig. 47 Change value &
Store
Fig. 48 Wash duration [sec]. Fig. 49 Wash duration
[min]..
Fig. 50 Cycle 1 Parameters. Fig. 51 Cycle 2 Parameters:
ENTER.
Fig. 52 Wash duration [min].
Fig. 53 Cycle 2 Parameters:
next Family
Fig. 54 Cycle 3 Parameters:
ENTER
Fig. 55 Wash duration [min].
FAC FAC
Cy1 Ln1
0 5h1
35
Cy1 Cy2
Ln2
…
Cy2 Cy3
Ln3
…
