10 MAIN BOARD CONFIGURATION
When receiving an electronic board (spare part) may be necessary to configure it in according to the machine
where has to be replaced
4. With the machine CODE enter into the following table and read the corresponding Prog. number
5. Follow the instructions reported into the corresponding Prog.XXX sheet (next pages).
6. With the machine CODE find the Layout number in Par. 12.2 CONNECTORS LAYOUT.
10.1 CODE -> Prog. TABLE
MODEL CODE Prog. Layout
EPPWELGM5
190400 140 4
EUC1/2
400035 101 11
EUC1DP/2
400036 101 11
EUC1WS/2
400037 102 21
EUC1DPWS/2
400038 102 21
EUC3/2
400040 103 16
NUC3DD
400041 103 16
EUC3WS/2
400044 104 17
EUC3DP/2
400045 103 16
EUC3DD/2
400046 103 16
EUC3DPWS/2
400047 104 17
EUC3DDWS/2
400048 104 17
ZUC1
400049 101 11
ZUC1DP
400050 101 11
ZUC1WS
400051 102 21
ZUC1DPWS
400052 102 21
ZUC3
400053 103 16
ZUC3WS
400054 104 17
EUC1
400055 101 11
EUC1DP
400056 101 11
EUC1WS
400057 102 21
EUC1DPWS
400058 102 21
EUC3
400059 103 16
EUC3WS
400060 104 17
EUC3DP
400061 103 16
EUC3DPWS
400062 104 17
EUC1G
400063 105 11
EUC1DP60
400064 101 11
EUC3DD
400065 103 16
ZUCADDROW
400066 134 16
ZUCADDROW6
400067 134 16
EUCADD60
400068 143 16
ZUC3DP
400069 103 16
ZUC3DD
400070 103 16
ZUC3DPWS
400071 104 17
ZUC3DDWS
400072 104 17
EUC1G/2
400073 105 11
EUA1DDG
400074 136 16
EUC1DP60
400075 101 11
ZUC1DP60
400076 101 11
EUC1GMS
400077 137 11
ZUC1G
400078 105 11
ZUCA1DDG
400079 136 16
ZUC1GMS
400080 137 11
VUC1
400081 101 11
VUC3
400082 103 16
VUC3G
400083 103 16
VUCA3WSG
400084 163 17
VUCA3G
400085 162 16
VUC1G
400086 105 11
EUCAGROWM
400095 170 16
EUCAGROW6M
400096 170 16
EUC3DDMCD
400097 165 12
FUCA3DD
400116 135 16
NUC1DPP
400120 101 11
EUC!DDM60
400121 101 11
NUC1DUK
400122 101 11
NUC1DDUK
400123 101 11
KUC3
400127 103 16
KUC3DP
400128 103 16
NUC1DDRUKP
400130 146 11
NUCA1GRUK
400131 136 16
NUC3DP
400132 103 16
NUC1
400133 101 11
NUC1DD
400134 101 11
EUCAIDP
400137 128 11
NUC1GMS
400138 137 11
EUC3DPCAG
400139 138 16
NUC1
400140 101 11
NUC1DP
400141 101 11
NUC1WS
400142 102 21
NUC1WSDP
400143 102 21
NUC3
400144 103 16
NUC3WS
400145 104 17
NUC3DP
400146 103 16
NUC3DPWS
400147 104 17
NUC3DDWS
400148 104 17
NUC1DP60
400149 101 11
NUC1DPA
400150 105 11
ZUCA1
400151 128 11
ZUCA3
400152 128 16
EUCADDROW
400153 134 16
EUCADDROW6
400154 134 16
NUC1DPDD
400155 101 11
NUCAIG
502010 106 8
NUCAIWSG
502011
107 8
Up to Ser.Nr 6361
NUCAIWSG
502011
154 8
From Ser.Nr 6371
XUCAI
502012 106 8
XUCAIDP
502013 106 8
VUCAIG
502021 164 8
EUCAI
502025 106 8
MODEL CODE Prog. Layout
