DOC. NO. 5956.65J.00 P. 18 / 174
EFS - Dishwashing Systems Platform
Electrolux Professional
8.4 Configuration Parameters
Sym. Parameter Description Unit Min Max
Factory
Default
Dishwasher Model:
0 = HOOD TYPE & UNDERCOUNTER
1 = POT WASHER
2 = AUTOMATIC POT WASHER
3 = MEDICAL LINE DISHWASHER WITH LOCK DOOR/HOOD
DEVICE
-03
0
Boiler type:
0 = ATMOSPHERIC BOILER
1 = PRESSURE BOILER
2 = EXTERNAL BOILER
-02
0
Door type:
0 = AUTOMATIC HOOD
1 = MANUAL HOOD
2 = FRONT LOADING
3 = POT WASHER
03
1
Default model (see Default tables):
1 = HOOD TYPE
2 = POT WASHER
3 = UNDERCOUNTER
-03
-
Solid State Relay (TRIAC).
0 = not enabled;
1 = SOFT START enabled;
3 = SLOW SOFT START enabled
(works only on boards with Solid State Relay)
.
-03
0
Boiler/Tank heating swap:
0 = boiler heaters and tank heater can work simultaneously;
1 = swap enabled: tank heating starts only boiler temperature is
reached;
2 = The booster heating elements and the wash pump have prior-
ity. The tank heating element is activated only when the booster
has reached the set temperature and the wash pump is not work-
ing.
(Note: disabling this function changes the global electrical power
of appliance; before enabling this function check available power,
supply cable section, fuses in according to User Manual).
-02
1
Tank Filling Mode
Enable filling tank by means of rinsing cycles
.
Ex: = 75 means that boiler water is heated at 75°C, then
follows a rinse phase and so on until tank is full.
If = 0 the tank is filled by solenoid valve in the traditional
way (On machines with incorporated continuous water softener,
even if
is set to 0, filling occurs through subsequent rinses).
[°C] 0 85
75
Detergent Level Switches
0 = level switches not enabled;
1 = enable detergent level switches;
-01
0
