DOC. NO. 5956.65J.00 P. 19 / 174
EFS - Dishwashing Systems Platform
Electrolux Professional
8.5  Parameters for automatic hood type dishwashers

USER INTERFACE MODEL
8 = ACTIVE function disabled
(up to version 3.11 [up to serial
nr. 42100099] set to 0)
9 = hood type, under counter (up to version 3.11 [up to serial
nr. 42100099] set to 1)
13 = LS5 with atmospheric boiler(up to version 3.11 [up to
serial nr. 42100099] set to 5)
15 = LS5 with pressure boiler (user interface without display); (up
to version 3.11 [up to serial nr. 42100099] set to 7)
24 = LS5 with atmospheric boiler (From Ser. Nr.: 821).
See parameter
(family ) to check the software version
installed in the board.
-027
9
Sym. Parameter Description Unit Min Max
Factory
Default

Enable “regeneration cycle” key (only for dishwashers with non-
continuous water softener) [See paragraph 9.1 RESIN REGEN-
ERATION CYCLE].
-01
0

ALARMS ENABLE
0 = alarms disabled (to disable also warnings see
 and
);
1 = alarms enabled;
If this function is disabled, faults can be detected so display do not
shows any alarm code.
-01
1

Air gap with float level sensor normally closed (the level sensor is
closed when the boiler is empty). E.g. the boiler level sensor for
machines with incorporated continuous water softener.
-01
0

Forced start of a resin regeneration cycle (only for dishwashers
with incorporated continuous water softener). [See paragraph 9.4
DISHWASHER WITH INCORPORATED CONTINUOUS WATER
SOFTENER].
-02
0

Max. rinse water hardness (only for dishwashers with incorpo-
rated continuous water softener). After modifying, disconnect and
reconnect the machine's main power supply by means of the
main switch. [See paragraph 9.4 DISHWASHER WITH INCOR-
PORATED CONTINUOUS WATER SOFTENER].
°fH 4 14
10

Boiler heating control.
Defines the max. permissible temperature difference during boiler
heating in a time interval of 2 minutes and 30 seconds.
°C 25 80
50
Sym. Parameter Description Unit Min Max
Factory
Default

DELAY_K1
Time (during hood lifting) within which S3” must return to the rest
position.
0.1 s 0.0 s. 20.0 s
15

HOOD_TOUT
TIMEOUT – max. time allowed for complete hood opening/clos-
ing.
0.1 s 0.0 s 20.0 s
200

DELAY_K1_S3
During hood lowering, firstly S3” must cut in and then after a time
 .the bottom limit switch S3.
0.1 s 0.0 s. 20.0 s 15

DELAY_K
Time within which K and K’ must be both closed or both open.
0.1 s 0.0 s. 20.0 s 10

DELAY_S3
Time during hood lifting within which the bottom limit switch must
return to the rest position..
0.1 s 0.0 s. 20.0 s 20
