DOC. NO. 5956.65J.00 P. 16 / 174
EFS - Dishwashing Systems Platform
Electrolux Professional
7.5 Drain/Cleaning Cycle Parameters
8 OTHER PARAMETERS
8.1 Dishwashing Parameters
Note: ,, , parameters emulates a two levels pressure switch, keep in mind that value
doesn’t correspond to a physical quantity.
Sym. Parameter Description Unit Min Max
Factory
Default
Initial Drain Phase Duration
[s] 0 240
40
Final Drain Phase Duration
[s] 0 240
80
Drain without cleaning cycle
-01
0
Number of wash cycles possible between one drain cycle and the
next
[wash
cycles]
0200 0
Indicates the maximum permissible delay between drain cycle
start and the reaching of a tank level below the work level. If the
set delay is exceeded, alarm B1 occurs.
[s] x 10 0 100 18
Sym. Parameter Description Unit Min Max
Factory
Default
Initial Pause before start washing (for ALL cycles)
[s] 0 10
0
Delay for the 2
nd
wash pump (PW only)
[s] 0 10
3
Active a drain phase at the end of washing phase.
[s] 0 40
0
Duration of pause after rinse cycle (valid for dishwashers with
door/hood lock device) [See par. 9.2 MEDICAL LINE DISH-
WASHER WITH DOOR/HOOD LOCK DEVICE].
[s] 0 60
0
Celsius/Fahrenheit selection
0 = Celsius
1 = Fahrenheit
-01
0
Rinse Temperature Display.
Enable rinse temperature probe (if installed).
0 = during rinse phase the display shows boiler temperature;
1 = during rinse phase the display shows rinse temperature;
-01
0
Pulse Per Litre.
This parameter must be settled in according to flow meter
installed [present up to software version 3.12].
[p/l] 0 255
0
Number of wash cycles performable without detergent (only for
dishwashers with external detergent level sensor – par. 9.3
DETERGENT AND RINSE AID LEVEL SENSORS ACTIVATION)
[
]
-05
5
Enable mode Thermal Label: if set to 1 it enables the mode and
disables the "endless cycle" button
-01 0
Boiler temperature in mode Thermal Label. [°C] 45 97 86
Tank temperature in mode Thermal Label. [°C] 40 90 75
Tank temperature hysteresis in mode Thermal Label. [°C] 0 30 2
Pressure sensor threshold 1 [present up to software version 2.11].
-0255
140
Pressure sensor histeresis 1 [present up to software version 2.11].
-0255
50
Pressure sensor threshold 2 [present up to software version 2.11].
-0255
140
Pressure sensor histeresis 2 [present up to software version 2.11].
-0255
50
