Electrolux FLE220 - Page 18

Edition
Service
Manual 12. Function Sequences
17 9108
12
Type
Page
L2
F1
S2
S1
K54
F2
S3
A
D
S32
K54
K54
S1
S2
N
50
X20:6
22
21
1
5
9
X3:7
51
52
218318319
X3:9
219
X8:1
3
4
X8:2
54
X20:4
11
12
2
3
2
4
A2
A1
72
6
10
52
S30
1
4
S4
X8:5
X8:6
55
203
204
62
53
B
C
2
X24:7
X24:9
1685
3
(1) F1 Fuse
(2) S2 Emergency stop
(3) S1 ON/OFF switch
(4) K54 Relay, start
(5) F2 Overheat protection
(6) S3 Switch, door
(7) S30 Switch, programmer
(8) S4 Switch, door lock
A B C : Power supply to
other function sequences
(9) S32 Switch, restart
(10) K54 Relay, start
(11) K54 Relay coil, start
D : Power supply to other function
sequences
(12) S1 ON/OFF switch
(13) S2 Emergency stop
