The following is a description of the test card supplied with the
machine. The basic procedure for programming (punching) cards is
described in chapter "5. Card Programming".
Function description of the card's 16 tracks
A Detergent, compartment 1
B Heating, index B on the thermostat
C Detergent, compartment 2
D Heating, index C on the thermostat
E Detergent dispensing
F Heating, index D on the thermostat
G Detergent dispensing
H Spin
I Detergent dispensing, compartment 3
K Drain
L Cold hard water (only certain machines)
M Programme stop, buzzer yellow signal light on
N High water level
O Inflow valve for cold water
P Cooling
Q Inflow valve for hot water
When connecting external metering equipment for liquid detergent,
use tracks A, C, E, G and I for pulse sending
The programme card/test card supplied with the machine is
programmed for normal soiled washing according to the following
description. In the table truncated pegs are marked "x" and remaining
pegs are marked ".".
