12. Function Sequences
12
17 9108
Page
Detergent
The machine has three built-in detergent compartments controlled by three
water valves. A total of five valves can also be controlled in an external
supply unit via connector X19. The following conditions must be met to
control the valves:
• The door must be closed and locked, and the programmer knob must be
in position I (see ”Power supply and start” sequence).
• Row M, stop (1) must not be programmed
• The out-of-balance switch must not have tripped (breaks K53:51-52 (2)
power supply)
• Row K, drain (3) must not be programmed
Once these conditions are met, the water valves can be controlled by
programming row A (4), detergent prewash, row C (6), detergent main
wash and row I (9), softener. Row E (7) and row G (8) can be used to
control another two valves in an external supply unit.
Row P (10) controls valve Y11b (14) which is used for cool-down (see
sequence '’Cool-down’').
Water valve Y11a/Y21 (12) can also be controlled manually with switch
S37 (5) on the machine control panel.
