Electrolux FLE220 - Page 26

12. Function Sequences Edition
Type
Service
Manual
17 9108
12
Page
11
K53
K
A
S37
C
E
G
I
P
Y11a/
Y21
Y12/
Y22
Y13
Y11b
D
52
51
3
1
2
3
1
2
3
1
2
3
1
2
3
1
2
3
1
2
3
1
2
1
2
X19
1
2
3
4
5
6
X9:1
X9:2
X9:5
X9:7
X9:9
A
M
63
1
2
3
C
62
67
69
54
80
81
82
83
84
85
77
4
A C : Power supply: see ”Power supply
and start” sequence
(1) Programmer, row M, stop
(2) Relay K 53, out-of-balance
(3) Programmer, row K, drain
(4) Programmer, row A,
detergent prewash V1
(5) Switch S37 , (detergent)
(6) Programmer, row C,
detergent main wash V2
(7) Programmer, row E, detergent V3
(8) Programmer, row G, detergent V4
(9) Programmer, row I,
softener V5
(10) Programmer, row P, cool-down
(11) Valve Y11a, cold water compartment 1 /
Y21, hot water compartment 1
(12) Valve Y12, cold water compartment 2 /Y22,
hot water compartment 2
(13) Valve Y13, cold water compartment 3
(14) Valve Y11b, cold water, cool-down
D : Power supply: see ”Power supply and
start” sequence
1687
